KENNAMETAL - WIDIA

TDCG SCREW ON INSERT TN7

WIDA2828508 MFG #: 2828508
$15.59 / EA
  • Insert Style: TDHH
  • Insert Size: 130805
  • Corner Radius: 0.007in
  • Manufacturer Grade: TN7
  • ISO Code: TDHH07S102L TN7
  • ANSI Code: TDHH130805L TN7
  • Included Angle: 60°
  • Shape: Triangular
  • Surface Treatment: Uncoated
  • Inscribed Circle: 0.16in
  • Applicable Materials: Steel, Stainless Steel, Cast Iron and Non-Ferrous Metals
  • Country of Origin: US
  • Hand Direction: Left Hand
  • Hole Diameter: 0.095in
  • Length: 0.277in
  • Manufacturer Name: WIDIA
  • Material: Cermet
  • Rake: Positive
  • Relief Angle: 15°
  • Thickness: 0.0469in
QTY
  • Application
  • Standards
Small Hole Boring Applications
ECCN: EAR99|PROP65: This product can expose you to chemicals including cobalt, which is known to the State of California to cause cancer. www.P65Warnings.ca.gov
