WNMP431-MF1 TM1501

WNMP431-MF1 TM1501

SEC03276714 03276714
234.90 / PK (10)
http://schema.org/OutOfStock
WNMP431-MF1 TM1501
  • Corner Radius: 0.016in, 0.4 mm, 0.4mm
  • Hand Direction: Neutral
  • Hole Diameter: 5.15 mm, 5.15mm
  • Included Angle: 80 deg, 80°
  • Inscribed Circle: 0.5in, 12.7 mm, 12.7mm
  • Insert Style: WNMP
  • ISO Code: WNMG080404
  • Material: Carbide
  • Rake: Negative
  • Relief Angle: 18 deg, 18°
  • Seat Size: 08, 8
  • Shape: Trigon
  • Surface Treatment: CVD, TiCN/Al2O3
  • Thickness: 0.187in, 4.76 mm, 4.76mm
  • Type: Insert
  • ANSI Designation: WNMP431-MF1
  • Clearance Angle: 0°
  • Country of Origin: SE
  • Cutting Edge Angle: 95°
  • Cutting Edge Length: 0.342in
  • Fixing Hole Diameter: 0.203in
  • Hand of Insert: Neutral
  • Has Attributes: Yes
  • Has Image: Yes
  • Insert Shape Code: W
  • ISO Designation: WNMG080404-MF1
  • Length: 8.54 mm, 8.54mm
  • Manufacturer Grade: TM1501
  • Manufacturer Name: Seco Tools
  • Old Manufacturer Number: 03276714
  • Series: WNMP
  • Tool Type: Insert
QTY
Add to List
  • Application
  • Item Features
  • Standards
For many continuous cut in stainless steel turning applications
  • Nanoscience at its best, the Duratomic CVD aluminum-oxide coating process manipulates coating components at an atomic level to improve the mechanical properties as well as the thermal and chemical inertness of many of the company's products
  • Duratomic graade, Highly resistant and optimized grade for many continuous cut in stainless steel turning applications
  • Complements in mixes of steel and stainless steel turning
  • Used Edge Detection (Chrome)
