WNMP331-MF1 TM2501 INSERT
WNMP331-MF1 TM2501 INSERT
SEC03276695
03276695
17.01
/ EA
http://schema.org/OutOfStock
/Product/SEC03276695
- Chipbreaker: MF1
- Corner Radius: 0.4 mm, 0.4mm
- Hand Direction: Neutral
- Hole Diameter: 3.81 mm, 3.81mm
- Included Angle: 80 deg, 80°
- Inscribed Circle: 9.525 mm, 9.525mm
- Insert Style: WNMP
- ISO Code: WNMG060404
- Material: Carbide
- Rake: Negative
- Relief Angle: 18 deg, 18°
- Shape: Trigon
- Surface Treatment: TiCN/Al2O3
- Thickness: 4.76 mm, 4.76mm
- Type: Insert
- Manufacturer Grade: TM2501
- Country of Origin: SE
- Has Attributes: Yes
- Has Image: Yes
- Length: 6.37 mm, 6.37mm
- Manufacturer Name: Seco Tools
- Series: WNMP
- Item Features
- Standards
- Nanoscience at its best, the Duratomic CVD aluminum-oxide coating process manipulates coating components at an atomic level to improve the mechanical properties as well as the thermal and chemical inertness of many of the company's products
- Duratomic grade,highly capable grade for austenitic stainless steel turning with combinations of high resistance and superior edge toughness
- First choice in austenitic stainless steel turning, complements in steel turning with heavy intermittent cuts
