WNMG433WETN610 TURNING INSERT
WNMG433WETN610 TURNING INSERT
KYOCTSS09112
TSS09112
8.69
/ EA
http://schema.org/OutOfStock
/Product/KYOCTSS09112
- Applicable Materials: Carbon/Alloy Steel
- Chipbreaker: WE
- Corner Radius: 3/64in
- Hand Direction: Neutral
- Hole Diameter: 0.2031in
- Included Angle: 80°
- Inscribed Circle: 1/2in
- Insert Size: #433
- Insert Style: WNMG
- ISO Code: WNMG080412WE
- Material: Cermet
- Material Grade: P
- Rake: Negative
- Relief Angle: 0°
- Seat Size: 8
- Shape: Trigon
- Surface Treatment: Uncoated/TiCN Coated
- Thickness: 3/16in
- Type: 6-Cutting Edge
- Manufacturer Grade: TN610
- ANSI Code: WNMG433WETN610
- Country of Origin: US|JP|CN|KR
- Has Attributes: Yes
- Has Image: Yes
- Manufacturer Name: KYOCERA Precision Tools
- Application
- Item Features
- Standards
External Turning, Facing, Boring and Internal Facing Applications
- Wiper edge with 6 cutting edges
- Three hybrid technology attributes maintain superior surface finish and machining stability
- Stable machining of steel
ECCN: EAR99
