WNMG433SGPR1535 TURNING INSERT

WNMG433SGPR1535 TURNING INSERT

KYOCTLC58656 TLC58656
9.89 / EA
http://schema.org/OutOfStock
  • Applicable Materials: Heat-Resistant Alloy, Stainless Steel and Titanium Alloy
  • Chipbreaker: SG
  • Corner Radius: 3/64in
  • Hand Direction: Neutral
  • Hole Diameter: 0.2031in
  • Included Angle: 80°
  • Inscribed Circle: 1/2in
  • Insert Size: #433
  • Insert Style: WNMG
  • ISO Code: WNMG080412SG
  • Material: Carbide
  • Material Grade: S, M
  • Rake: Negative
  • Relief Angle:
  • Seat Size: 8
  • Shape: Trigon
  • Surface Treatment: PVD-MEGACOAT NANO
  • Thickness: 3/16in
  • Type: 6-Cutting Edge
  • Manufacturer Grade: PR1535
  • ANSI Code: WNMG433SGPR1535
  • Country of Origin: US|JP|CN|KR
  • Has Attributes: Yes
  • Has Image: Yes
  • Manufacturer Name: KYOCERA Precision Tools
  • Series: PR15
QTY
  • Application
  • Item Features
  • Standards
External Turning, Facing, Boring and Internal Facing Applications
  • Heat-resistant alloy with 6 cutting edges
  • Stabilized turning operations and long tool life with MEGACOAT NANO coating technology
  • PVD for titanium alloy and precipitation hardened stainless steel
ECCN: EAR99
