1/16 x7Deg x.816 RCH NF MOLD
1/16 x7Deg x.816 RCH NF MOLD
HATL995621
995621
78.00
/ EA
http://schema.org/OutOfStock
/Product/HATL995621
- Cutter Diameter Decimal Inch: 0.062
- Cutter Diameter Fractional Inch: 1/16
- Cutter Diameter Metric: 1.575
- Type: Type II High Helix Tapered Reach
- Number of Flutes: 2
- Length of Cut Decimal Inch: 0.05
- Length of Cut Metric: 1.27
- Overall Length Decimal Inch: 2.5
- Overall Length Fractional Inch: 2-1/2
- Overall Length Metric: 63.5
- Material: Solid Carbide
- Surface Treatment: UNCOATED
- Helix Angle: 45 deg
- Shank Diameter Decimal Inch: 0.25
- Shank Diameter Fractional Inch: 1/4
- Shank Type: Cylindrical
- Country of Origin: US
- Flute Type: Upcut
- Hand Direction: Right Hand
- Has Attributes: Yes
- Has Image: Yes
- Manufacturer Name: Harvey Tool
- Neck Angle: 7°
- Overall Reach: 0.816in
- Item Features
- Standards
- Very short length of cut and solid tapered neck for maximum rigidity
- 1 deg, 1.5 deg, 3 deg, 5 deg, and 7 deg neck angles to address common draft angles in molds
- 45 deg helix, large flute valley, and sharper cutting edge for faster chip removal and better finish
- Offered with TiB2 coating to minimize galling and enhance performance
- 2 flutes to center
- Applicable Materials are Aluminum, Cast Iron, Steel, Stainless Steel, Wood, Composites
- Neck Angle 7
- Type II
- Overall Reach 0.8160 in
- Profile Ball
PROP65: This product contains chemicals known to the State of California to cause cancer
