CAT50 ER32 4"GL COLLET CHUCK
CAT50 ER32 4"GL COLLET CHUCK
TEC22311S
22311S
170.00
/ EA
http://schema.org/OutOfStock
/Product/TEC22311S
- Chuck Size: ER32
- Collet Nut Diameter: 1.97in
- Collet System: ER32
- Head Length/Projection: 1.1in
- Nose Diameter: 1.969in
- Overall Length Decimal Inch: 5.1
- Overall Length Metric: 129.54
- Shank Type: Tapered
- Taper Size: CAT50
- Through Coolant (Yes/No): Yes
- Has Attributes: Yes
- Has Image: Yes
- Type: Precision Single End Super Rigid V-Flange
- Item Features
- Collet chucks are balanced to 25000 rpm at G2.5 tolerance
- Super rigid chucks offer the best TIR and z-axis of any collet chuck
- They are individually lab tested for accuracy and balance and come with their individual performance report
- Super rigid chucks are perfect for high torque or high speed machining and offer minimal projection length
