SVJBL 82JXFF TURNING TOOL HOLDER

SVJBL 82JXFF TURNING TOOL HOLDER

KYOCTHC89704 THC89704
131.81 / EA
http://schema.org/OutOfStock
SVJBL 82JXFF TURNING TOOL HOLDER
  • Hand Direction: Left Hand
  • Lead Angle: 93 deg
  • Material: Steel
  • Overall Length Decimal Inch: 4.75
  • Overall Length Fractional Inch: 4-3/4
  • Overall Length Metric: 120.65
  • Rake: Positive
  • Shank Size: 1/2 in W x 1/2 in H
  • Tool Holder Style: SVJB-FF
  • ANSI Code: SVJBL82JXFF
  • Back of Bar to Cutting Edge: 1/2 in
  • Country of Origin: US|JP|CN|KR
  • Has Attributes: Yes
  • Has Image: Yes
  • Inscribed Circle: 1/4 in
  • Insert Seat Size: 1/8 in
  • Insert Style: VBMT22…/VBGT22…/VBET22…/VBGW22…
  • ISO Code: SVJBL8-2JXFF
  • Manufacturer Name: KYOCERA Precision Tools
  • Series: SSTH
  • Type: Multi-Use
QTY
Add to List
  • Application
  • Item Features
  • Standards
Copying, External Turning, Small Parts Machining and Swiss Applications
  • Screw clamp insert holding design
  • Simple mechanism with fewer parts for finishing to medium machining
  • Without coolant-through
ECCN: EAR99
