S10HSWUBR0607A POSITIVE RAKE BORING BAR

S10HSWUBR0607A POSITIVE RAKE BORING BAR

KYOCTHC11972 THC11972
134.13 / EA
http://schema.org/OutOfStock
S10HSWUBR0607A POSITIVE RAKE BORING BAR
  • Inscribed Circle: 3.97 mm
  • Insert Shape: 80 deg Trigon
  • Insert Style: WBMT121…/WBGT121…/WBGW121…
  • Insert Thickness: 1.59 mm
  • Material: Steel
  • Maximum Bore Depth: 25 mm
  • Minimum Bore Diameter: 7 mm
  • Overall Length Decimal Inch: 100
  • Overall Length Metric: 2540
  • Shank Diameter Decimal Inch: 0.394
  • Shank Diameter Metric: 10
  • Shank Type: Round
  • Through Coolant (Yes/No): No
  • Type: Positive Rake
  • Country of Origin: US|JP|CN|KR
  • Hand of Holder: Right Hand
  • Has Attributes: Yes
  • Has Image: Yes
  • Manufacturer Name: KYOCERA Precision Tools
  • Series: DYNB
  • Toolholder Type: S...SWUB-A
QTY
Add to List
  • Application
  • Item Features
  • Standards
Boring Applications
  • Maximum structural thickness for higher toolholder rigidity and controlled chattering for stable machining
  • Large chip pocket provides superior chip evacuation
  • Anti-chatter vibration performance
  • Maintains high cutting edge positional accuracy through the use of a special alloy, thereby achieving high precision machining
  • 0 (axial), -13 (radial) rake angle dynamic bar Boring Bar
ECCN: EAR99
