3/16" 2FL .030R 3x CR CARB END MILL

3/16" 2FL .030R 3x CR CARB END MILL

HATL46730 46730
36.10 / EA
http://schema.org/OutOfStock
3/16" DIA x .030CR 2FL CARBIDE END MILL
  • Type: Center Cut Imperial Variable Pitch
  • Cutter Diameter Decimal Inch: 1
  • Cutter Diameter Fractional Inch: 1
  • Cutter Diameter Metric: 25.4
  • Number of Flutes: 3
  • Length of Cut Decimal Inch: 1.25
  • Length of Cut Fractional Inch: 1-1/4
  • Length of Cut Metric: 31.75
  • Overall Length Decimal Inch: 6
  • Overall Length Fractional Inch: 6
  • Overall Length Metric: 152.4
  • Material: Carbide
  • Surface Treatment: UNCOATED
  • Helix Angle: 40°
  • Shank Diameter Decimal Inch: 1
  • Shank Diameter Fractional Inch: 1
  • Shank Type: Reduced
  • Series: H40ALV-RN-3
  • Flute Type: Spiral
  • Has Attributes: Yes
  • Has Image: Yes
This 3 flute, 40 deg helix end mill for aluminum has a variable pitch design that reduces chatter and harmonics, prolonging tool life and leaving a higher quality part finish. Its reduced neck design provides it with maximum strength in long reach and deep pocketing applications.
QTY
Add to List
  • Application
  • Item Features
Long Reach and Deep Pocketing Applications
  • Unique 3 teeth to center end geometry for ramping applications
  • Reduced neck provides maximum strength in long reach and deep pocketing applications
  • Wiper flat design leaves superior floor finish
  • Excellent performance in high efficiency milling (HEM)
  • h6 shank tolerance for high precision tool holders
  • Uncoated tool offers an excellent option for aluminum finishing applications
