SPMW422 UP20M SPMW120308 UP20M
SPMW422 UP20M SPMW120308 UP20M
MIT106033
106033
12.35
/ EA
http://schema.org/OutOfStock
/Product/MIT106033
- ANSI Code: SPMW422 UP20M
- Insert Style: SPMW
- Material: Carbide
- Type: Without Wiper
- Corner Radius: 0.8 mm
- Chipbreaker: Flat Top
- ISO Code: SPMW120308 UP20M
- Included Angle: 90 deg
- Shape: Square
- Inscribed Circle: 12.7 mm
- Cutting Direction: Neutral
- Has Attributes: Yes
- Has Image: Yes
- Hole Diameter: 0.224 in
- Length: 12.7 mm
- Manufacturer Name: Mitsubishi Materials USA Corp
- Manufacturer's Grade: UP20M
- Rake: Positive
- Relief Angle: 11 deg
- Thickness: 3.18 mm
- Application
For Cast Iron
