DNMU331-MF1 TM2501
DNMU331-MF1 TM2501
SEC03276317
03276317
266.83
/ PK (10)
http://schema.org/OutOfStock
/Product/SEC03276317
- Chipbreaker: MF1
- Corner Radius: 0.016in, 0.4 mm, 0.4mm
- Hand Direction: Neutral
- Hole Diameter: 3.81 mm, 3.81mm
- Included Angle: 55 deg, 55°
- Inscribed Circle: 0.375in, 9.525 mm, 9.525mm
- Insert Style: DNMU
- ISO Code: DNMU110404
- Material: Carbide
- Rake: Negative
- Relief Angle: 18 deg, 18°
- Seat Size: 11
- Shape: Diamond
- Surface Treatment: CVD, TiCN/Al2O3
- Thickness: 0.187in, 4.76 mm, 4.76mm
- Type: Insert
- ANSI Designation: DNMU331-MF1
- Clearance Angle: 0°
- Country of Origin: SE
- Cutting Edge Angle: 93°
- Cutting Edge Length: 0.458in
- Fixing Hole Diameter: 0.15in
- Hand of Insert: Neutral
- Has Attributes: Yes
- Has Image: Yes
- Insert Shape Code: D
- ISO Designation: DNMU110404-MF1
- Length: 9.65 mm, 9.65mm
- Manufacturer Grade: TM2501
- Manufacturer Name: Seco Tools
- Old Manufacturer Number: 03276317
- Series: DNMU
- Tool Type: Insert
- Item Features
- Standards
- Nanoscience at its best, the Duratomic CVD aluminum-oxide coating process manipulates coating components at an atomic level to improve the mechanical properties as well as the thermal and chemical inertness of many of the company's products
- Duratomic grade,highly capable grade for austenitic stainless steel turning with combinations of high resistance and superior edge toughness
- First choice in austenitic stainless steel turning, complements in steel turning with heavy intermittent cuts
- Used Edge Detection (Chrome)
