DNMG 442-NRM:T7335 TURNING INSERT - NEGATIVE
DNMG 442-NRM:T7335 TURNING INSERT - NEGATIVE
PRA7595932
7595932
15.32
/ EA
http://schema.org/OutOfStock
/Product/PRA7595932
- Applicable Materials: Stainless Steel
- Chipbreaker: NRM
- Corner Radius: 0.8mm
- Hole Diameter: 5.16mm
- Included Angle: 55°
- Inscribed Circle: 12.7mm
- Insert Size: 150608
- Insert Style: DNMG
- ISO Code: DNMG 150608-NRM:T7335
- Material: Carbide
- Maximum Depth of Cut Decimal Inch: 0.157
- Maximum Depth of Cut Metric: 4.0
- Rake: Negative
- Relief Angle: 0°
- Shape: Rhomboid
- Surface Treatment: MT-CVD Coated
- Thickness: 6.35mm
- Type: Double Sided Metric
- ANSI Code: DNMG 442-NRM:T7335
- Has Attributes: Yes
- Has Image: Yes
- Manufacturer Grade: T7335
Double-sided negative turning insert, 55° rhomboid with inscribed circle diameter of 12.7mm, 6.35mm thick, 0.8mm nose radius and indexing accuracy according to ISO-tolerance class-M, chip-breaker NRM, in grade T7335, a MT-CVD coated functionally graded WC-Co carbide within ISO range M20-M40, for medium to heavy machining of stainless-steels
- Item Features
- Standards
- Very positive effect on tool life - cooling is recommended
- External cooling supply
