CNMM 644-HR2:T9226 TURNING INSERT - NEGATIVE
CNMM 644-HR2:T9226 TURNING INSERT - NEGATIVE
PRA7036347
7036347
23.60
/ EA
http://schema.org/OutOfStock
/Product/PRA7036347
- Applicable Materials: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys
- Chipbreaker: HR2
- Corner Radius: 1.6mm
- Hole Diameter: 7.94mm
- Included Angle: 80°
- Inscribed Circle: 19.05mm
- Insert Size: 644
- Insert Style: CNMM
- ISO Code: CNMM 190616E-HR2:T9226
- Material: Carbide
- Material Grade: K, M, P, S
- Maximum Depth of Cut Decimal Inch: 0.512
- Maximum Depth of Cut Metric: 13.0
- Rake: Negative
- Relief Angle: 0°
- Seat Size: 19
- Shape: Diamond
- Surface Treatment: CVD Coated
- Thickness: 6.35mm
- Type: 19.3mm
- ANSI Code: CNMM 644-HR2:T9226
- Has Attributes: Yes
- Has Image: Yes
- Manufacturer Grade: T9226
Single-sided negative turning insert, 80° rhomboid with inscribed circle diameter of 19.05mm, 6.35mm thick, 1.6mm nose radius and indexing accuracy according to ISO-tolerance class-M, chip-breaker HR2, in grade T9226, a MT-CVD coated functionally graded WC-Co carbide within ISO range P15-P35, for heavy to extra heavy machining of steels
- Application
- Item Features
- Standards
Roughing to Heavy Roughing Applications
- T9226 grade greater cutting edge strength with the new functional gradient substrate containing a higher cobalt bonding phase and finer grain
- Reduced adhesion of the workpiece material thanks to special treatment added to the coating's surface
- Exceptional performance in heavy turning operations
- Higher operational reliability
- Ideally suited to for adverse machining conditions
- Resistance to formation of heat related cracks
