CNMM 43XLSX PR115S TURNING INSERT

CNMM 43XLSX PR115S TURNING INSERT

KYOCTLV00032 TLV00032
9.11 / EA
http://schema.org/OutOfStock
CNMM 43XLSX PR115S TURNING INSERT
  • Applicable Materials: Heat-Resistant Alloy
  • Chipbreaker: SX
  • Corner Radius: 0.031 in
  • Hand Direction: Left Hand
  • Hole Diameter: 0.203 in
  • Included Angle: 80 deg
  • Inscribed Circle: 1/2 in
  • Insert Size: 43
  • Insert Style: CNMM
  • ISO Code: CNMM1204XL-SX
  • Material: Carbide
  • Material Grade: S
  • Rake: Negative
  • Relief Angle: 0 deg
  • Shape: Diamond
  • Surface Treatment: PVD
  • Thickness: 3/16 in
  • Type: 2-Cutting Edge
  • ANSI Code: CNMM43XLSXPR115S
  • Country of Origin: US|JP|CN|KR
  • Has Attributes: Yes
  • Has Image: Yes
  • Manufacturer Grade: PR115S
  • Manufacturer Name: KYOCERA Precision Tools
  • Series: ISOI
QTY
Add to List
  • Application
  • Item Features
  • Standards
For Boring, External Turning, Facing, Internal Facing
  • Insert for External Turning, Facing, Boring, Internal Facing
  • Heat-Resistant Alloy with 2 Cutting Edges
  • Improved thermal conductivity by optimum distribution of WC coarse grains in the substrate
  • Resists heat concentration at the cutting edge to promote stable machining
