DCMW 21505S00435MET KBN010 INSERT
DCMW 21505S00435MET KBN010 INSERT
KYOCTFD00085
TFD00085
77.50
/ EA
http://schema.org/OutOfStock
/Product/KYOCTFD00085
- Applicable Materials: Hardened Materials
- Corner Radius: 0.008 in
- Hand Direction: Neutral
- Hole Diameter: 0.11 in
- Included Angle: 55 deg
- Inscribed Circle: 1/4 in
- Insert Size: 21505
- Insert Style: DCMW
- ISO Code: DCMW070202S01035MET
- Material: CBN
- Material Grade: H
- Rake: Positive
- Relief Angle: 7 deg
- Shape: Diamond
- Surface Treatment: PVD
- Thickness: 3/32 in
- ANSI Code: DCMW21505S00435METKBN010
- Country of Origin: US|JP|CN|KR
- Has Attributes: Yes
- Has Image: Yes
- Manufacturer Grade: KBN010
- Manufacturer Name: KYOCERA Precision Tools
- Series: ISOI
- Application
- Item Features
- Standards
For Back Boring, Copying, External Turning
- Combination of new coating technology and high content CBN provides exceptional wear resistance and fracture resistance
- Newly developed MEGACOAT TOUGH coating technology
- New adhesion layer is laminated between the high wear resistance layer and the CBN
- Reduces layer peeling to achieve long tool life and stable machining
ANSI
