CNG432T00825PT600M TURNING INSERT

CNG432T00825PT600M TURNING INSERT

KYOCTCV01208 TCV01208
18.61 / EA
http://schema.org/OutOfStock
CNG432T00825PT600M TURNING INSERT
  • Applicable Materials: Gray Cast Iron and Hardened Material
  • Corner Radius: 1/32in
  • Hand Direction: Neutral
  • Included Angle: 80°
  • Inscribed Circle: 1/2in
  • Insert Size: #432
  • Insert Style: CNG
  • ISO Code: CNGN120408T02025
  • Material: Ceramic
  • Material Grade: H, K
  • Rake: Negative
  • Relief Angle: 0°
  • Seat Size: 12
  • Shape: Rhombic
  • Surface Treatment: Al2O3/TiC/PVD-MEGACOAT
  • Thickness: 3/16in
  • Type: 4-Cutting Edge
  • ANSI Code: CNG432T00825PT600M
  • Country of Origin: US|JP|CN|KR
  • Has Attributes: Yes
  • Has Image: Yes
  • Manufacturer Grade: PT600M
  • Manufacturer Name: KYOCERA Precision Tools
QTY
Add to List
  • Application
  • Item Features
  • Standards
External Turning and Facing Applications
  • Heat-resistant MEGACOAT coating on aluminum oxide and titanium carbide ceramic
  • Semi-roughing to finishing of cast iron, hard materials and hardened roll materials
  • https://s3-us-west-2.amazonaws.com/catsy.739/14_DRA_GM_SS400_Exit_Slowmotion.mp4
ECCN: EAR99
