CNM433KBN900 TURNING INSERT

CNM433KBN900 TURNING INSERT

KYOCTBP01011 TBP01011
323.01 / EA
http://schema.org/OutOfStock
CNM433KBN900 TURNING INSERT
  • Applicable Materials: Cast Iron
  • Corner Radius: 0.047in
  • Hand Direction: Neutral
  • Hole Diameter: 0.203in
  • Included Angle: 80°
  • Inscribed Circle: 1/2in
  • Insert Size: 433
  • Insert Style: CNMN
  • ISO Code: CNMN120412 KBN900
  • Material: CBN
  • Material Grade: K
  • Rake: Negative
  • Relief Angle: 0°
  • Seat Size: 12
  • Shape: Diamond
  • Surface Treatment: TiN Coated
  • Thickness: 3/16in
  • ANSI Code: CNM433 KBN900
  • Country of Origin: JP
  • Has Attributes: Yes
  • Has Image: Yes
  • Manufacturer Grade: KBN900
  • Manufacturer Name: KYOCERA Precision Tools
QTY
Add to List
  • Application
  • Item Features
General Turning Applications
  • KBN900 grade TiN coated solid CBN
  • Heavy duty, interrupted cutting and finishing of hardened steel, hardened roll steel and cast iron
