135N 3/16" 2FL CC .008CR CARBIDE END MILL
135N 3/16" 2FL CC .008CR CARBIDE END MILL
MAF13518751N
13518751N
24.48
/ EA
http://schema.org/OutOfStock
/Product/MAF13518751N
- Corner Radius: 0.008 in
- Cutter Diameter: 3/16 in
- Cutter Diameter Decimal Inch: 0.1875
- Cutter Diameter Fractional Inch: 3/16
- Cutter Diameter Metric: 4.762
- Number of Flutes: 2
- Length of Cut: 1/4 in
- Length of Cut Decimal Inch: 0.25
- Length of Cut Fractional Inch: 1/4
- Length of Cut Metric: 6.35
- Overall Length: 3 in
- Overall Length Decimal Inch: 3
- Overall Length Fractional Inch: 3
- Overall Length Metric: 76.2
- Material: Carbide
- Helix Angle: 30 deg
- Shank Diameter: 3/16 in
- Shank Diameter Decimal Inch: 0.1875
- Shank Diameter Fractional Inch: 3/16
- Shank Type: Straight
- Country of Origin: US
- Cutting Direction: Right Hand
- Manufacturer Name: M.A. Ford
- Type: Center Cutting Corner Radius
M.A. Ford® TuffCut® End Mills perform better and last significantly longer than competitive products, minimizing process downtime and maximizing productivity and cost efficiency. Included in our product line are high performance end mills developed for specific applications such as stainless steels and high temperature alloys, hardened steel, titanium, composite material, aluminum and softer alloys.
- Application
- Item Features
- Standards
High Performance
- Solid carbide end mill allows it to be run at extremely high chip loads surpassing the current market leaders
- For high speed machining of aluminum and non-ferrous metals
- Whisper blend transition between OD and neck
- Reduced vibration harmonics
- Improved part finishes
- Maintains cutting edge strength and sharpness for improved tool life
- Slotting at 1X Dia deep
- 1-9/16 in L neck
- 0.008 in corner radius
ISO 9001:2008
