16ER08UNTQPR1535 THREADING INSERT

16ER08UNTQPR1535 THREADING INSERT

KYOCTLC19798 TLC19798
15.15 / EA
http://schema.org/OutOfStock
16ER08UNTQPR1535 THREADING INSERT
  • ANSI Code: 16ER08UNTQPR1535
  • Chipbreaker: TQ
  • Corner Radius: 0.0169in
  • Country of Origin: US|JP|CN|KR
  • Hand Direction: Right Hand
  • Included Angle: 60°
  • Inscribed Circle: 3/8in
  • Insert Size: #16
  • Insert Style: 16ER
  • ISO Code: 16ER08UN-TQ
  • Manufacturer Name: KYOCERA Precision Tools
  • Material: Carbide
  • Material Grade: M
  • Series: PR15
  • Surface Treatment: PVD-MEGACOAT NANO
  • Thread Standard: Unified, UNF
  • Thread Type: External
  • Threads Per Inch: 8
  • Type: 3-Cutting Edge
  • Manufacturer Grade: PR1535
  • Thickness: 0.145in
  • Has Attributes: Yes
  • Has Image: Yes
QTY
Add to List
  • Application
  • Item Features
  • Standards
For PVD for titanium alloy and precipitation hardened stainless steel and external threading
  • 60 deg full profile for unified threads
  • Stabilized turning operations and long tool life with MEGACOAT NANO coating technology
ECCN: EAR99
